1963 Triumph Spitfire Specifications

Specifications

1962 1963 1964

Features

Engine Location :	Front
Drive Type :	Rear Wheel
Body / Chassis :	Steel body on steel frame
Production Years for Series :	1962 - 1964
Price :	$2,200
Weight :	1475 lbs \| 669.049 kg

Performance

0-60 mph :	17.3 seconds.
Top Speed :	145 km/h \| 90.118 mph

Engine & Transmission

Straight 4
Displacement :	1147 cc \| 70.0 cu in. \| 1.1 L.
Power :	63 BHP (46.368 KW) @ 5750 RPM
Torque :	67 Ft-Lbs (91 NM) @ 3500 RPM
Bore :	2.7 in \| 69 mm.
Stroke :	3.0 in \| 76 mm.
Compression :	8.5:1
Main Bearings :	3
Valvetrain :	8 OHV (2.0 valves per cylinder)
Cylinder Block :	Cast-iron
Ignition system :	2 SU carbs

Transmission:
4 Manual , 4 Manual with Overdrive

Production Figures

Total Triumph Production for 1963 :	20,117
Mk 1 / Spitfire4 Production (1962-1964) :	45,753
1963 Triumph Spitfire

Handling

1963 Averages

Avg. Car Cost :	$3,233
Avg. Household Income :	$5,807
Avg. Home :	$12,650
Avg. Gallon of Gas :	$0.29

1963 Triumph Spitfire FAQs (show)

Popular frequently asked questions include:

What are the dimension and mechanical specifications of the 1963 Triumph Spitfire?
How many 1963 Triumph Spitfire were produced?
How powerful was the 1963 Triumph Spitfire? Was the 1963 Triumph Spitfire popular? Was the 1963 Triumph Spitfire expensive? What was the fuel economy of the 1963 Triumph Spitfire?

Q: How fast is the 1963 Triumph Spitfire? A: The 1963 Triumph Spitfire has a top speed of 145 km/h.

Q: What is the wheelbase size of the 1963 Triumph Spitfire? A: The 1963 Triumph Spitfire has a wheelbase size of 83.00 inches.

Q: What is the length of the 1963 Triumph Spitfire? A: The 1963 Triumph Spitfire has a length of 145.00 inches.

Q: What is the width of the 1963 Triumph Spitfire? A: The 1963 Triumph Spitfire has a width of 57.00 inches.

Q: How much did the 1963 Triumph Spitfire cost when new?A: The 1963 Triumph Spitfire had a base price of approximately $2,200 (USD).

Q: What is the bodystyle of the 1963 Triumph Spitfire? A: The 1963 Triumph Spitfire was a Roadster.

Q: How many vehicles did Triumph produce in 1963? A: Triumph produced 20,117 automobiles in 1963.

Q: How many Mk 1 / Spitfire4 were produced? A: Triumph produced 45,753 examples of the Mk 1 / Spitfire4 from 1962 to 1964.

Q: What engine did the 1963 Triumph Spitfire have? A: The engine powering the 1963 Triumph Spitfire was a Straight 4 (1147 cc | 70.0 cu in. | 1.1 L.) with 63 BHP (46.368 KW) @ 5750 RPM and 67 Ft-Lbs (91 NM) @ 3500 RPM.

Q: What transmissions did the 1963 Triumph Spitfire have? A: The 1963 Triumph Spitfire had the following gearbox options: 4 speed Manual, 4 speed Manual with Overdrive.
